Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.7.14. Command Details: Prm_Begin_Ind
Category
Extended
Details
Command Code: 1Fh
Valid For: Object Instance
Description
This command is optional. The module issues this command to indicate to the host application that a
parameterization phase, outside of the connection establishment, is initiated. During the parameterization
phase the host application may receive Set_Record commands targeting the submodules addressed by the
Prm_Begin_Ind command.
• Command Details
Msg field Contents
CmdExt[0] AR handle (low byte)
CmdExt[1] AR handle (high byte)
Data[0] API (low word, low byte)
Data[1] API (low word, high byte)
Data[2] API (high word, low byte)
Data[3] API (high word, high byte)
Data[4] Slot (low byte)
Data[5] Slot (high byte)
Data[6] Sub-slot (low byte)
Data[7] Sub-slot (high byte)
• Response Details
(no data)
Page 130 of 177
Comments
Handle for the Application Relationship (AR)
Application Process Instance
Only valid if Sub-slot > 0
Slot number affected by the command
Only valid if Sub-slot > 0
Sub-slot number affected by the command
0 — Command applies to all modules in the configuration
>0 — Command applies to the specified slot/sub-slot
PROFINET IO Object (F6h)
