Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.3. Asset Management Object (E5h)
11.3.1. Category
Extended
11.3.2. Object Description
This object implements asset management information, i.e. identification information about one or several non
PROFINET components of a device. Each component is represented by one object instance. The application
collects identification information and assembles it in the instance attributes for each object instance.
11.3.3. Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
11.3.4. Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
11.3.5. Instance Attributes (Instance #1 - #32)
Asset management data for a non PROFINET component is represented by one of three different formats
depending on the complexity of the component. For a complex component based on both hardware and
software the format AM_Full information comply. For hardware-only components the format AM_HardwareOnly
complies, and for software-only components the AM_FirmwareOnly format is used.
Which format to use for a specific component is selected by attribute AM_InfoType.
Both AM_HardwareOnly and AM_FirmwareOnly are subsets of AM_Full. If AM_HardwareOnly is selected the
attributes AM_SoftwareRevision and IM_Software_Revision are of no interest and thus not read by the Anybus
CompactCom. In the same manner, if AM_FirmwareOnly is selected the attributes AM_HardwareRevision and
IM_Hardware_Revision are of no interest and thus not read by the Anybus CompactCom.
Page 96 of 177
Access Data Type Value
Get Array of CHAR "Asset management"
Get UINT8 01h
Get UINT16 Max 32. Depends on number of non PROFINET components.
Get UINT16 Max 32. Depends on number of non PROFINET components.
Asset Management Object (E5h)
SCM-1202-021 Version 2.6
