Network Configuration Object (04h)
10.5. Network Configuration Object (04h)
10.5.1. Category
Extended
10.5.2. Object Description
This object holds network specific configuration parameters that may be set by the end user. A reset command
(factory default) issued towards this object will result in all instances being set to their default values.
As soon as the used combination of IP address, Subnet mask and Gateway is changed, the module informs the
application by writing the new set to instance #1, attribute #16 in the Ethernet Host Object (F9h).
See also...
• Communication Settings (page 9)
• Ethernet Host Object (F9h) (page 132)
IMPORTANT
Allowing the following instances to be set by the host application during start-up will inhibit the
possibility to pass conformance tests.
10.5.3. Supported Commands
Object: Get_Attribute
Reset
Instance: Get_Attribute
Set_Attribute
Get_Enum_String
10.5.4. Object Attributes (Instance #0)
# Name
3 Number of instances
4 Highest instance number
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
10.5.5. Instance Attributes (Instance #3, IP Address)
Value is used after module reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
SCM-1202-021 Version 2.6
Access Data Type Value
Get UINT16 10
Get UINT16 21
Access Data Type Description
Get Array of CHAR "IP address"
(Multilingual, see page
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of UINT8 If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of UINT8 Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Description
Supported number of instances
Highest instance number
Multilingual Strings (page
Ethernet
54))
