PROFINET IO Object (F6h)
11.7.5. Instance Attributes (Instance #1)
Basic
# Name Access
1 Device ID Get
2 Vendor ID (I&M Get
Manufacturer ID)
3 Station Type Get
8 I&M Order ID Get
9 I&M Serial Number Get
GSD Entries
The GSDML entries below must match the values of the corresponding attributes in the PROFINET IO object.
• Attributes #1 and #2 correspond to the following entry in the GSDML file:
<DeviceIdentity VendorID="0x010C" DeviceID="0x0010">
• Attribute #8 correspond to the following entry in the GSDML file:
<OrderNumber Value="CompactCom 40 PIR"/>
Extended
• If an attribute is not implemented, the default value will be used.
• The Anybus module in itself does not alter its behavior based on the value of attributes #13 and #14. The host
application has to implement the corresponding functionality.
• The module is preprogrammed with a valid Mac address. To use that address, do not implement attributes #17
and #18.
SCM-1202-021 Version 2.6
Data Type Default
UINT16 0010h
UINT16 010Ch (HMS
Industrial Networks)
Array of "CompactCom 40
CHAR PIR"
Array of "CompactCom 40
CHAR PIR"
Array of Assigned during
CHAR manufacturing
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Comment
Identifies the device. (Assigned by manufacturer) If not
implemented, the default value will be used.
(Assigned by PROFIBUS & PROFINET International (PI)) If not
implemented, the default value will be used.
Characterizes the device. Assigned by manufacturer); up to 25
characters. If not implemented, the value of attribute #9 (Product
name) in the Application Object (FFh), will be used. If this attribute is
not implemented, the default value will be used.
I&M0 Parameter: Order ID of device; up to 20 characters. If not
implemented, the default value will be used.
I&M0 Parameter: Serial number of device; up to 16 characters.
If not implemented, the value of attribute #3 (Serial number) in
the Application Object (FFh), will be used. If this attribute is not
implemented, the default value will be used.
Ethernet
