Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.5. Sync Object (EEh)
11.5.1. Category
Extended
11.5.2. Object Description
This object contains the host object sync settings.
The implementation of this object is optional. If it is not implemented the Anybus CompactCom 40 PROFINET IRT
can not be used for a synchronous application.
If there is any problem with the configuration of the sync functionality as a whole, the application must indicate
this in the application status register. The Anybus CompactCom will then change states and inform the problem
to the PROFINET IO Controller, see
See also ...
• Anybus CompactCom 40 Software Design Guide, "Sync"
• Anybus CompactCom 40 Software Design Guide, "Sync Object"
11.5.3. Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Set_Attribute
11.5.4. Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Page 102 of 177
Application Status Register (page 137).
SCM-1202-021 Version 2.6
Sync Object (EEh)
