Network Specific — PROFINET
Keywords
Keyword
GSDML-DeviceProfile version
DeviceIdentity->DeviceID
DeviceAccessPointItem->CheckDeviceID_Allowed
DeviceAccessPointItem->ImplementationType
DeviceAccessPointItem->WebServer
DeviceAccessPointItem->LLDP_NoD_Supported
DeviceAccessPointItem->PowerOnToCommReady
DeviceAccessPointItem->ResetToFactoryModes
DeviceAccessPointItem->PNIO_Version
ModuleInfo->HardwareRelease Value
ModuleInfo->SoftwareRelease Value
CertificationInfo->ConformanceClass
CertificationInfo->NetloadClass
VirtualSubmoduleItem->API
VirtualSubmoduleItem->IOData IOPS_Length
VirtualSubmoduleItem->IOData IOCS_Length
VirtualSubmoduleItem->Writeable_IM_Records
VirtualSubmoduleItem->MayIssueProcessAlarm
InterfaceSubmoduleItem->PTP_BoundarySupported
InterfaceSubmoduleItem->DCP_HelloSupported
InterfaceSubmoduleItem-
>DelayMeasurementSupported
InterfaceSubmoduleItem-
>SupportedDelayMeasurements
InterfaceSubmoduleItem->RT_Class3Properties
InterfaceSubmoduleItem->SynchronisationMode
ApplicationRelations->StartupMode
MediaRedundancy SupportedRole="Client"
SupportsRingportConfig="true"
IsDefaultRingport="true"
VirtualSubmoduleItem->Writeable_IM_Records="1 2
3"
SCM-1202-021 Version 2.6
®
Anybus
Comments
2.31 for 30-series, 2.42 for 40-series
Must be changed to reflect the Device ID you have configured in the PROFINET IO object
(F6h), Attribute 1
False for 30-series, true for 40-series
NP30 for 30-series, NP40 for 40-series
Optional keyword. Can be removed if not used
Mandatory, =true for 40-series
Required if Fast Start-Up is supported
2 in 30-series, 2 and 8 in 40-series (2 mandatory)
V2.2 in 30-series, V2.32 in 40-series
Optional. Removed in 40-series
Optional. Removed in 40-series
B in 30-series, B or C in 40-series depending on IRT
Mandatory. III in 40-series
Removed in 40-series. API=0 default
Removed in 40-series. Default=1
Removed in 40-series. Default=1
1 2 3 4 in 30-series. 1 2 3 in 40-series
Mandatory for 2.32. False in 40-series
False in 30-series, true in 40-series
True - Required if FSU is supported
Only for IRT (40-series)
Only for IRT (40-series)
Only for IRT (40-series)
Only for IRT (40-series)
Legacy in 30-series. Legacy and Advance in 40-series (mandatory)
New MRP keyword in the 40-series. MRP not supported in 30-series
New MRP keyword in the 40-series. MRP not supported in 30-series
New MRP keyword in the 40-series. MRP not supported in 30-series
I&M4 removed in the 40-series
™
CompactCom 40 - PROFINET IRT Transparent
