Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
10.7. Network Ethernet Object (0Ch)
10.7.1. Category
Extended
10.7.2. Object Description
This object provides Ethernet-specific information to the application.
The object has three instances, each corresponding to a port:
Instance #
1
2
3
Each instance provides statistic counters for the port with the MAC address given in attribute #4. This
information can e.g be presented on internal web pages, if present, using the JSON script language.
NOTE
Instance attributes #1 - #3 are reserved and used for backwards compatibility with earlier
applications.
10.7.3. Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
10.7.4. Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
Page 56 of 177
Port
Internal port
Port 1
Port 2
Access Data Type Value
Get Array of CHAR "Network Ethernet"
Get UINT8 01h
Get UINT16 3
Get UINT16 3
Network Ethernet Object (0Ch)
