Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.4. Functional Safety Object (E8h)
11.4.1. Category
Extended
11.4.2. Object Description
IMPORTANT
Do not implement this object if a safety module is not used.
This object specifies the safety settings of the application. It is mandatory if Functional Safety is to be supported
and a Safety Module is connected to the Anybus CompactCom module.
11.4.3. Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
11.4.4. Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
Page 100 of 177
Access Data Type Value
Get Array of CHAR "Functional Safety"
Get UINT8 01h
Get UINT16 0001h
Get UINT16 0001h
Functional Safety Object (E8h)
SCM-1202-021 Version 2.6
