Network PROFINET IO Object (0Eh)
10.8.5. Instance Attributes (Instance #1)
Extended
# Name
1 OnLineTrans
2 OffLineTrans
3 (reserved)
4 Last AbortInd ReasonCode
5 AddedApis
6 ApiList
7 EstablishedArs
8 ArList
9 -
10 Port 1 MAC Address
11 Port 2 MAC Address
SCM-1202-021 Version 2.6
Access Type Value
Get UINT32 Diagnostic counters; keeps track of the number of on-line transitions
Get UINT32 Diagnostic counters; keeps track of the number of off-line transitions
Get UINT16 Reason code for most recent Abort indication
See command details for command AR_Abort
Get UINT16 Returns the number of APIs added (including API 0)
Get Array of UINT32 First element will always be zero and the second element will contain
an additional API. Length of the array is determined by parameter
"AddedApis".
Get UINT16 The number of Application Relationships currently established
Get Array of UINT16 Array of Application Relationship handles. Length of array is determined
by parameter "EstablishedArs".
- - -
Get Array of UINT8 6 Byte PROFINET Port 1 MAC address
See also...
- Ethernet Host Object (F9h) (page 132)
Get Array of UINT8 6 Byte PROFINET Port 2 MAC address
See also...
- Ethernet Host Object (F9h) (page 132)
® ™
