Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
10.7.7. Media Counters
Array indices of Media Counters attribute (#6)
Index Name
0 AlignmentErrors;
1 FCSErrors;
2 SingleCollisions;
3 MultipleCollisions;
4 SQETestErrors;
5 DeferredTransmissions;
6 LateCollisions;
7 ExcessiveCollisions;
8 lMACTransmitErrors;
9 lCarrieSenseErrors;
10 lFrameTooLong;
11 lMACRecieveErrors;
Page 58 of 177
Description
Frames received that are not an integral number of octets in length
Frames received that do not pass the FCS check
Successfully transmitted frames which experienced exactly one collision
Successfully transmitted frames which experienced more than one collision
Number of times SQE test error is generated
Frames for which first transmission attempt is delayed because the medium is
busy
Number of times collision is detected later than 512 bit-times into the
transmission of a packet
Frames for which transmission fails due to excessive collisions
Frames for which transmission fails due to an internal MAC sublayer transmit
error
Times that the carrier sense condition was lost or never asserted when
attempting to transmit a frame
Frames received that exceed the maximum permitted frame size
Frames for which reception on an interface fails due to an internal MAC
sublayer receive error
Network Ethernet Object (0Ch)
