PROFINET IO Object (F6h)
# Name Access
18 Port 2 MAC Get
address
19-23 (Reserved) -
24 Custom Get
Station
Name
25 IM Module Get
Order ID
26 IM Get
Annotation
27 IM5 Enabled Get
28 S2 Enabled Get
29 S2 Primary Set
AR handle
30 DAP module Get
ident
SCM-1202-021 Version 2.6
Data Type Default Value
Array of -
UINT8
- -
Array of Product specific.
CHAR (default:
"CompactCom-40-
PIR")
Array of Anybus
CHAR CompactCom 40
PROFINET IRT
Array of Anybus
CHAR CompactCom 40
PROFINET IRT
BOOL True
BOOL False
UINT16 0
UINT32 Standard DAP:
80010000h
Fiber-optic DAP:
80010002h
®
Anybus CompactCom
Comment
6 byte physical address value; overrides the preprogrammed Mac address.
Do not implement this attribute if the preprogrammed Mac address is to
be used.
Reserved, not used
When using shift register mode, this value is used to create the station
name.
If for example the attribute has the value abcc40-pir, the station name will
be abcc40-pir-XYZ where XYZ is the value of DIP2.
Valid characters are letters "a" to "z", numbers "0" to "9", hyphens and
periods. The attribute value must begin with a letter.
Maximum number of elements in array: 58
For more information, see the Anybus CompactCom M40 Hardware
Design Guide.
I&M5 parameter.
Order ID of the communication interface.
Maximum number of elements in array is 64.
Not available for Anybus IP.
I&M5 parameter
Description of the communication interface.
Maximum number of elements in array: 64.
Not available for Anybus IP.
Enable I&M5 support.
True: I&M5 enabled
False: I&M5 disabled
Enable S2 system redundancy.
True: S2 enabled
False: S2 disabled
AR handle of currently primary AR when S2 is enabled (attribute #28).
A switchover (Backup to Primary) or loss of Primary triggers an update of
the AR handle indicating change of primary AR.
The handle may be used by the application to reference AR specific
commands; e.g. AR_Check_Ind that contains IP address and Station name
of the IO controller.
The value 0 indicates "No Primary AR" or "No S2 connection".
DAP module ident number used in ADI-based configuration.
The host application may provide different idents for different products
that are part of a device family. Products in a device family may be
represented as DAPs in a single GSDML file.
NOTE
The DAP module ident must be a unique module ident in
the GSDML file.
The value is not allowed to be 0.
™
40 - PROFINET IRT Transparent
Ethernet
