Routing Restrictions Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
• X3-XX-00-00-00-00
(X: any number 0-F)
8.5.3. UDP/TCP Ports
The following ports may be used by the Anybus CompactCom, and must not be used by the host application:
• UDP 67 & 68 (DHCP)
• UDP 161 (SNMP)
• UDP 3250 (HICP)
The following ports are reserved for use by PROFINET:
• UDP 34962 (PROFINET RT Unicast)
• UDP 34963 (PROFINET RT Multicast)
• UDP 34964 (PROFINET RPC Context Manager)
• UDP 53247 (PROFINET RPC Client/Server)
The following ports are reserved for use by EtherNet/IP:
• UDP 2222 (Implicit messaging)
• UDP & TCP 44818 (Explicit messaging)
The following port is reserved for use by Modbus TCP:
• TCP 502 (Modbus messaging)
