Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
IMPORTANT
This attribute should not be set by the application at every power on, as this would cause
certification problems.
10.5.6. Instance Attributes (Instance #4, Subnet Mask)
Value is used after module reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
IMPORTANT
This attribute should not be set by the application at every power on, as this would cause
certification problems.
10.5.7. Instance Attributes (Instance #5, Gateway Address)
Value is used after module reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
IMPORTANT
This attribute should not be set by the application at every power on, as this would cause
certification problems.
10.5.8. Instance Attributes (Instance #6, DHCP Enable)
Value is used after module reset.
Page 50 of 177
Access Data Type Description
Get Array of CHAR "Subnet mask"
(Multilingual, see page
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of UINT8 If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of UINT8 Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Access Data Type Description
Get Array of CHAR "Gateway"
(Multilingual, see page
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of UINT8 If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of UINT8 Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Network Configuration Object (04h)
Multilingual Strings (page 54))
Multilingual Strings (page 54))
