Design Guidelines
Transport System Design
Multiple Paths
Loop Transport System with Switches:
One Ethernet Connection for Main Loop
RS-422 Connections for Spurs
Power Supply (not shown) – Inline from Switch or Star
Three Paths
x.y.0.10
HLC &
Node
Controller
Host Enet
Ethernet
Controller Switch
P1M10
x.y.1.10
QSHT 5700
Inverter
QSHT 5700
Inverter
P1M9
x.y.1.9
Figure 3-27: Ethernet Motor Wiring – Three Paths, Ethernet Chain Main Loop, RS-422 Spur
88
RS-422
P3M1
x.y.3.1
QSMC
Motor
Controller
P1M11
x.y.1.11
QSHT 5700
Inverter
Diverge
QSHT Motor QSHT Motor
QSMC
Motor
Controller
P2M1
x.y.2.1
QSHT Motor QSHT Motor
QSHT 5700 QSHT 5700
Inverter Inverter
P1M8 P1M7
x.y.1.8 x.y.1.7
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
P3M2 P3M3
x.y.3.2 x.y.3.3
QSMC QSMC
Motor Motor
Controller Controller
QSHT Motor
Downstream
Merge
QSHT Motor QSHT Motor
QSMC QSMC
Motor Motor
Controller Controller
P2M2 P2M3
x.y.2.2 x.y.2.3
QSHT Motor QSHT Motor
QSHT 5700 QSHT 5700
Inverter Inverter
P1M6 P1M5
x.y.1.6 x.y.1.5
P1M1 P1M2
x.y.1.1 x.y.1.2
QSHT 5700 QSHT 5700
Inverter Inverter
QSHT Motor
QSHT Motor
QSHT 5700 QSHT 5700
Inverter Inverter
P1M4 P1M3
x.y.1.4 x.y.1.3
Drive
Sense
Ethernet
RS-422
MagneMotion
