Qty
Description
3
1 m motor
3
QSMC motor controller
25
1/2 m motor
13
QSMC-2 motor controller
3
Paths
2
Nodes
1 Diverge
1 Merge
1
Node Controller (NC)
NOTE: Arrows indicate direction of forward motion.
Figure 3-4: Sample QSHT Transport System Layout Showing Node Controllers
QuickStick HT User Manual
NC
&
HLC
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Motor Drives
Path 3
Design Guidelines
Transport System Layout
Diverge
Path 2
Merge
63
