Specifications and Site Requirements
Electrical Specifications
Menu/Submenu
BACKLIGHT TIMEOUT
CYCLIC DATA SELECT
MAIN MENU
MODULE INFO
MOTOR INFO
DIAGNOSTICS
DRIVE DIAGNOSTICS
166
Table 4-50: LCD Pages (Continued)
30 SEC – Backlight turns off 30 seconds after last button push.
1 MIN – Backlight turns off 1 minute after last button push.
1 MIN – Backlight turns off 3 minutes after last button push.
5 MIN – Backlight turns off 5 minutes after last button push.
10 MIN – Backlight turns off 10 minutes after last button push.
NEVER – Backlight is always on.
BUS VOLT – Bus voltage is displayed in the home page
(0.0 - 600.0 V).
INV TEMP – Inverter temperature is displayed in the home page
(0.0 - 80.0 C).
MOTOR TEMP – Motor temperature is displayed in the home page
(0.0 - 80.0 C).
OUT CUR – Inverter out current is displayed in the home page
(0.0 - 20.0 A).
MODULE INFO – Selects the MODULE INFO page.
MOTOR INFO – Selects the MOTOR INFO page.
DIAGNOSTICS – Selects the DIAGNOSTICS page.
CATALOG NUMBER – Catalog number (24 character string max).
FW – Firmware revision (major.minor.patch format ex. 1.23.456)
HW REV – Hardware revision (2 character string).
SERIAL# – Serial number (6 character string ex. R123456).
MODEL – Configured motor model number (1 METER, HALF
METER, DUAL HALF, DOUBLE WIDE).
SERIAL# – Motor serial number (12 character string ex.
MMI161000084).
MOTOR TYPE – Actual motor type number (1 METER, HALF
METER, DUAL HALF, DOUBLE WIDE).
DRIVE DIAGNOSTICS – Selects the DRIVE DIAGNOSTICS page.
MOTOR DIAGNOSTICS – Selects the MOTOR DIAGNOSTICS
page.
SAFETY INPUTS – Selects the SAFETTY INPUTS page.
SAFETY DIAGNOSTICS – Selects the SAFETY DIAGNOSTICS
page.
DC BUS – The DC bus voltage of currently selected inverter
(0.0 - 900.0 V).
INV TEMP – Temperature of currently selected inverter
(0.0 - 80.0 C).
