<Motor> <!-- P2M2 -->
<Mac_addr>C0:6C:6D:E0:00:2A</Mac_addr>
<IP_addr>10.14.2.2</IP_addr>
<Track_location>P2M2</Track_location>
</Motor>
<Motor> <!-- P2M3 -->
<Mac_addr>C0:6C:6D:E0:00:2C</Mac_addr>
<IP_addr>10.14.2.3</IP_addr>
<Track_location>P2M3</Track_location>
</Motor>
<!-- PATH 3 -->
<Motor> <!-- P3M1 -->
<Mac_addr>C0:6C:6D:E0:00:50</Mac_addr>
<IP_addr>10.14.3.1</IP_addr>
<Track_location>P3M1</Track_location>
</Motor>
<Motor> <!-- P3M2 -->
<Mac_addr>C0:6C:6D:E0:00:2D</Mac_addr>
<IP_addr>10.14.3.2</IP_addr>
<Track_location>P2M3</Track_location>
</Motor>
<Motor> <!-- P3M3 -->
<Mac_addr>C0:6C:6D:E0:00:29</Mac_addr>
<IP_addr>10.14.3.3</IP_addr>
<Track_location>P3M3</Track_location>
</Motor>
</MICS_motor_data>
QuickStick HT User Manual
<!-- Motor IP address -->
<!-- Motor IP address -->
<!-- Motor IP address -->
<!-- Motor IP address -->
<!-- Motor IP address -->
Figure 3-29: MICS File Example (Continued)
