Motor/QSMC Sense Cable

The QSMC motor controllers are supplied with motor (stator) sense cables, which provide
feedback from the motor. This cable is available in lengths from 2 m to 20 m. Contact Magne-
Motion for replacement cables. The motor sense cable connects directly to the QSMC motor
controller and to the related motor.
700-1685-xx
Motor Controller
+V
GND
RS-422
RS-422
RS-422
RS-422
NOTICE
QuickStick HT User Manual
Figure 4-12: QSMC to Stator Sense Cable
Table 4-7: QSMC to Stator Sense Cable Pinouts
Motor Controller
Wire M12 Eurofast, 6-Pin,
Gauge Male
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
Modifications to the MMI motor to motor controller cables,
or using custom cables, violates the UL conditions of accept-
ability.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Specifications and Site Requirements
1 1
M12 Eurofast, 6-Pin,
1
2
3
4
5
6
Electrical Specifications
Motor
Motor
Female
1
2
3
4
5
6
