Ground Configuration
Grounded (wye)
• AC-fed ungrounded
• Corner grounded
• Impedance grounded
DC-bus from active converter
* The QSHT 5700 inverter must be spaced by aligning the zero-stack tab and cutout. For hole patterns, refer to
the Kinetix 5700 Servo Drives User Manual, publication 2198-UM002.
QuickStick HT User Manual
Table 5-4: QSHT 5700 Inverter Ground Screw Configurations
Ground Screw
*
Configuration
Installed
Not installed (default
setting)
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Transport System Installation
Benefits of Configuration
UL and EMC compliance.
Reduced electrical noise.
Most stable operation.
Reduced voltage stress on components
and motor bearings.
Helps avoid severe equipment damage
when ground fault occurs.
Reduced leakage current.
Installation
