Motor/QSHT 5700 Inverter Sense Cable

The QuickStick HT 5700 inverter is supplied with motor (stator) sense cables, which provide
feedback from the motor. This cable is available in lengths from 2 m to 30 m. Contact Magne-
Motion for replacement cables. The motor sense cable connects directly to the QSHT 5700
inverter and to the related motor.
MMI-HT-CBS00-xx
Inverter
Vcc
Vcc
COM
COM
Shield
RS-422 Rx+
RS-422 Rx-
RS-422 Tx+
RS-422 Tx-
NC
NOTICE
QuickStick HT User Manual
Figure 4-15: QSHT 5700 Inverter to Stator Sense Cable
Table 4-11: QSHT 5700 Inverter to Stator Sense Cable Pinouts
Wire
Gauge
22 AWG
22 AWG
22 AWG
22 AWG
22 AWG
22 AWG
22 AWG
22 AWG
22 AWG
22 AWG
Modifications to the MMI motor to inverter cables, or using
custom cables, violates the UL conditions of acceptability.
