Operation

Controls and Indicators

Controls and Indicators
The control application on the host controller must provide any needed controls or indicators
that are related to transport system operation. Additional controls and indicators can be con-
figured as described in this section. The controls and indicators of the QuickStick HT compo-
nents are identified in the

Track Display

The NCHost TCP Interface Utility can be used to display the Graphics Window, which is
shown in Figure
cles in the transport system for real-time monitoring of transport system operation. This dis-
play can only be used if there is a Track file for the specific configuration (created by
MagneMotion). See the NCHost TCP Interface Utility User Manual,
Graphics Window.
250
Electrical Specifications on page
6-12. The Graphics Window shows the transport system layout and all vehi-
Figure 6-12: The Graphics Window
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
133.
MMI-UM010 to use the
