Motor Drive To Motor Drive - Rockwell Automation MagneMotion QuickStick HT User Manual

End 'A'
(Motor)
Nano-Mizer F
Nano-Mizer F
Nano-Mizer F
4
3
M8 Nano-Mizer
4-Pin, Female
End 'A'
RxD+
RxD-
TxD+
TxD-

Motor Drive to Motor Drive

An RS-422 daisy chain cable is used to connect the downstream end of the QSMC motor con-
troller for one motor to the upstream end of the QSMC motor controller for the next motor in
the path. This cable is a standard pin-to-pin straight through cable with a 4-pin female M8
connector on one end and a 4-pin female M8 connector on the other end. One female M8 con-
nector plugs into the downstream communication port on the motor drive and the other M8
connector plugs into the upstream communication port on the next motor drive.
QuickStick HT User Manual
Figure 4-22: RS-422 Cables
Table 4-51: RS-422 Cable Pinouts
2
2
1
7
®
,
1 TxD+
2 TxD-
3 RxD+
4 RxD-
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Specifications and Site Requirements
50 m Max
3 3
8 8
DE-9, Male DE-9, Female
End 'B'
3
8
7
2
Communications
End 'B'
(Node Controller)
DE-9M
DE-9F
Nano-Mizer F
2
4
3
7
M8 Nano-Mizer,
4-Pin, Female
7 3
2 4
3 1
8 2
2
1
171
