Specifications and Site Requirements
Electrical Specifications
MMI-HT-CBP05-xx
Inverter
Table 4-10: 1/2 m QSHT 5700 Inverter to Stator Drive Cable Pinouts
Stator Block 1, Phase A
Stator Block 1, Phase B
Stator Block 1, Phase C
Gnd
Shield
NOTICE
140
Figure 4-14: 1/2 m QSHT 5700 Inverter to Stator Drive Cable
Wire
Gauge
16 AWG
16 AWG
16 AWG
16 AWG
BRAID
Modifications to the MMI motor to inverter cables, or using
custom cables, violates the UL conditions of acceptability.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Inverter
U
V
W
PE
Exposed Braid
Motor
A
F
A
E
G
B
D C
Motor
A
B
C
G
Shell
MagneMotion
