Mounting the QuickStick HT 5700 Inverters

Install the QSHT 5700 inverters system inside an approved metal enclosure (IP54 min). Run
input power wiring in conduit (grounded to the enclosure) outside of the enclosure. Separate
signal and power cables. The QuickStick HT 5700 (QSHT 5700) inverters must be spaced in
the enclosure by aligning the zero-stack tab and cutout as shown in
terns, see the Kinetix 5700 Servo Drives User Manual, 2198-UM002. Make sure that the ser-
vice and exclusion zones that are identified in
Zero-stack Tab/Cutout
2198-Pxxx PS
The QuickStick HT 5700 inverter is powered by the 2198-Pxxx DC-bus power supply (see
Input Power Configurations for Kinetix 5700 Power Supplies and Ground Screw/Jumper Set-
tings in the Kinetix 5700 Servo Drives User Manual, 2198-UM002). The example shown in
Figure 5-2 is powered by the DC-bus power supply (positioned on the left) with inverter mod-
ules mounted to the right.
The QSHT 5700 inverter mounts with the 2198-Pxxx DC-bus power supplies using the Rock-
well Automation zero-stack tab and cutout system. See the Kinetix 5700 DC-bus Power Sup-
ply Installation Instructions, 2198-IN009.
QuickStick HT User Manual
(typical)
MOD
NET
2
1
1
4
I/O
(typical)
Figure 5-2: QSHT 5700 Inverter Mounting
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Transport System Installation
Figure
Figure 4-7 on page 130
Shared-bus Connection Systems
(DC-bus and 24V DC)
Installation
5-2. For hole pat-
are maintained.
QSHT 5700 Inverter
(typical)
