Installation
Transport System Installation

Mounting the 2198-Pxxx DC-bus Power Supplies

Install the 2198-Pxxx DC-bus power supplies inside the approved metal enclosure (IP54 min)
where the inverters are installed. Run input power wiring in conduit (grounded to the enclo-
sure) outside of the enclosure. Separate signal and power cables. The 2198-Pxxx DC-bus
power supplies and QSHT 5700 inverters must be spaced in the enclosure by aligning the
zero-stack tab and cutout as shown in
Drives User Manual, 2198-UM002.
QSHT 5700 Drive System Power Supply Ground Screw/Jumper Settings
Determine the ground screw/jumper setting for the 2198-Pxxx DC-bus power supply and
QSHT 5700 inverters. The 2198-Pxxx DC-bus power supplies have a factory-installed ground
screw for grounded-wye power distribution.
tings for the 2198-Pxxx DC-bus power supply.
Table 5-2: Ground Screw/Jumper Setting for the DC-bus Power Supply
Ground Configuration
Grounded (wye)
• Impedance grounded
• Corner grounded
• AC-fed ungrounded
* Ground screw is factory installed.
To access the ground screw on the 2198-Pxxx DC-bus power supplies, open the small plastic
door on the right side of the module as shown in
ground screw be installed with the power supply removed from the panel and placed on its
side on a solid surface equipped as a grounded static-safe workstation.
IMPORTANT If the facility uses a grounded-wye power distribution, do not
IMPORTANT If grounded-wye power distribution is being used with a
186
Figure
Ground screw installed (default setting)
Remove ground screw/jumper
remove the ground screw from the DC-bus power supply.
Remove the ground screw when using ungrounded, cor-
ner-grounded, or impedance-grounded power.
2198-Pxxx DC-bus power supply, install the ground screw.
For grounded-wye power distribution, EMC performance
can be affected if the ground screw is not installed.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
5-2. For hole patterns, see the Kinetix 5700 Servo
Table 5-2 details the ground screw/jumper set-
2198-Pxxx DC-bus Power Supply
Figure 5-3. It is recommended that the
*
