Specifications and Site Requirements
Electrical Specifications
Table 4-19: QSMC Motor Controller Stator Drive Connector Pinout
Table 4-20: QSMC Motor Controller HVDC Power Connector Pinout
146
A
16S-1S, 7-Pin, Female
Stator Block 1, Phase A
Stator Block 1, Phase B
Stator Block 1, Phase C
Stator Block 2, Phase A
Stator Block 2, Phase B
Stator Block 2, Phase C
GND
Key
2
Powerfast, 3-Pin, Male
GND
PWR RTN
PWR HI
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
A
B
C
D
E
F
G
1
3
1
2
3
MagneMotion
