QuickStick HT 5700 Inverter Controls and Indicators

The QSHT 5700 inverter has two status indicators and an LCD status display, shown in
Figure 4-20. The indicators and display are used to monitor the system status, set network
parameters, and troubleshoot faults. There are additional status indicators on the network con-
nectors. Four navigation buttons, directly below the display, are used to select items from a
soft menu.
Indicators
IMPORTANT Status indicators are not reliable for safety functions. Use
Condition
Steady Off
Steady Green
Flashing green
Flashing red
Steady Red
Flashing Green/Red
Condition
Steady Off
Steady Green
Flashing green
Flashing red
Steady Red
Flashing Green/Red
QuickStick HT User Manual
them only for general diagnostics during commissioning or
troubleshooting. Do not attempt to use status indicators to
determine operational status.
Table 4-44: Module Status Indicator
No power is applied to the drive.
—
Drive is operational. No faults or failures.
Major recoverable fault. The drive detected a recoverable fault, for
example, an Incorrect or Inconsistent configuration.
Major fault. The drive detected a nonrecoverable fault.
Self-test. The drive performs self-test during power-up.
Table 4-45: Network Status Indicator
No power is applied to the drive.
Drive has obtained an IP address.
—
IP Address is not configured
Duplicate IP address. IP address specified is already in use.
Self-test. The drive performs self-test during power-up.
