See Figure 4-9
nection locations on the QSHT 5700 inverters. See the Node Controller Hardware User Man-
ual, MMI-UM013, for the communication connection locations on the node controllers. See
Figure 5-10 for a detailed example.
When connecting the inverters to the node controllers, both ends of a path do not need to con-
nect to the same node controller. However, all connections to the inverters for motors at the
ends of all paths that meet in a node must be made to the same node controller. See the Quick-
Stick Configurator User Manual, MMI-UM009, for more information about nodes and paths.
Power Connector
1/2 m QSHT
2198-Pxxx
DC Bus
Power Supply
Figure 5-10: QSHT Motor and QSHT 5700 Inverter Communications Connections
QuickStick HT User Manual
for the connection locations on the QSHT motors and
Sense Connector
1 m QSHT
(typical)
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
(typical)
Node
Controller
Ethernet Cable
(typical)
Installation
Transport System Installation
Figure 4-20 for the con-
QSHT 5700
Inverter
Network
Switch
197
