Electrical Specifications

Motors (Stators)

• 1 m – See
Meter Motor on page 124
• 1/2 m – See
See 1/2 Meter Motor on page 125
• 1/2 m Double-wide – See
ifications. See
NOTE: The motor power is supplied by the external QSMC motor controller or QSHT 5700
inverter, see
on page 154
motor drive and the motor must be capable of carrying the full load.
Upstream
Label
Drive
Sense
Ground
NOTE: The drive and sense cables have a 90° bend at the motor connector. The bend is
located such that the cable direction is as shown in
QuickStick HT User Manual
QSMC Motor Controller on page 127
for the mechanical drawing.
QSMC-2 Motor Controller on page 128
QSMC Motor Controller on page 127
1/2 Meter Double-wide Motor on page 126
QSMC Motor Controller on page 142
as appropriate for power requirements. All power wiring between the
Ground
Bottom View
Figure 4-9: Motor Electrical Connections
Table 4-2: Motor Connections
Description
Motor block phase power
Motor block control signals
Motor chassis ground
SHOCK HAZARD: 400V DC maximum, 15 A maximum.
DC power must be disconnected before servicing.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Specifications and Site Requirements
for the electrical specifications. See
for the electrical specifications.
for the mechanical drawing.
or QuickStick HT 5700 Inverter
Drive Sense
Connector Type
3-Point Bayonet, Size 16S, 7-Pin, Male
M12 Eurofast, 6-Pin, Male
M6 x 1–6H, 8.0 mm max depth
Figure 4-9
Electrical Specifications
for the electrical spec-
for the mechanical drawing.
Downstream
when connected.
