Motor/QSMC Power Cable

The QSMC motor controllers are supplied with appropriate motor (stator) drive cables, which
provide power to the phases of the motor. These cables are available in lengths from 2 m to
20 m. Contact MagneMotion for replacement cables. The motor drive cable connects directly
to the QSMC motor controller and to the related motor.
700-1537-xx
Motor Controller
Stator Block 1, Phase A
Stator Block 1, Phase B
Stator Block 1, Phase C
Stator Block 2, Phase A
Stator Block 2, Phase B
Stator Block 2, Phase C
GND
NOTICE
QuickStick HT User Manual
Figure 4-10: 1 m QSMC to Stator Drive Cable
Table 4-5: 1 m QSMC to Stator Drive Cable Pinouts
Motor Controller
Wire 3-Pt Reverse Bayonet,
Gauge
16 AWG
16 AWG
16 AWG
16 AWG
16 AWG
16 AWG
16 AWG
Modifications to the MMI motor to motor controller cables,
or using custom cables, violates the UL conditions of accept-
ability.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Specifications and Site Requirements
A A
16S-1, Male
A
B
C
D
E
F
G
Electrical Specifications
Motor
Motor
3-Pt Reverse Bayonet,
16S-1, Female
A
B
C
D
E
F
G
