Unpacking and Inspection

Unpacking and Inspection
The QuickStick HT transport system components are shipped in separate packages. Open
each package carefully following the steps that are provided in
page 177; inspect and verify the contents against the shipping documents. Report any damage
immediately to the shipper and to MagneMotion.
One set of shipping documents is attached to the outside of the main shipping crate for easy
access.
NOTE: The number and contents of the shipping packages depends on the items purchased.
See the shipping documents for the exact contents. The checklist in
vided for reference only.
Package
QuickStick HT Motors
Motor Drives
Magnet Arrays
Node Controllers
Power Supplies
Installation Kit
176
Table 5-1: QuickStick HT Packing Checklist Reference
QuickStick HT linear synchronous motors.
Controllers or inverters for the QSHT motors.
Magnet arrays to be attached to the vehicles as the motor second-
ary to provide material movement on the transport system.
MagneMotion node controllers for managing the nodes in the
transport system.
Power supplies to provide logic and propulsion power to the
QuickStick HT motors.
• Miscellaneous hardware.
• Cables.
• User Manuals, drawings, and so on.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Unpacking and Moving on
Table 5-1
Contents
is pro-
MagneMotion
