Design Guidelines
Transport System Design
Straight Transport System:
One Ethernet Connection per Motor
Multiple Ethernet Switches, Star Topology
Power Supply - Star to first Switch
One Path
Host Enet
Controller Switch
Enet
Switch
Figure 3-18: Ethernet Motor Wiring – One Path, Ethernet Star, Multiple Ethernet Switches
Straight Transport System:
One Ethernet Connection per Motor
Multiple Subnets, Multiple Ethernet Switches
Star Topology
Power Supply - Star to each Switch
Two Paths
10.14.0.100
Host
Controller
Enet
Router
Figure 3-19: Ethernet Motor Wiring – Two Paths, Ethernet Star, Multiple Node Controllers
82
Simple QSHT Motor
QSHT 5700
Inverter
P1M1
Ethernet
x.y.1.1
x.y.0.10
HLC &
Node
Controller
Ethernet
Simple QSHT Motor
QSHT 5700
Inverter
x.14.0.1
P1M1
Ethernet
x.14.1.1
Enet
Switch
x.14.0.10
HLC &
Node
Controller
x.15.0.1
Ethernet
Enet
Switch
x.15.0.10
Node
Controller
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Downstream
QSHT Motor QSHT Motor
QSHT 5700 QSHT 5700
Inverter Inverter
P1M2 P1M3
x.y.1.2 x.y.1.3
Downstream
QSHT Motor Relay QSHT Motor
QSHT 5700 QSHT 5700
Inverter Inverter
P1M2 P2M1
x.14.1.2 x.15.2.1
QSHT Motor Term
QSHT 5700
Inverter
P1M4
x.y.1.4
QSHT Motor Term
QSHT 5700
Inverter
P2M2
x.15.2.2
