Universal Feedback Connector Kit Wiring Requirements - Rockwell Automation MagneMotion QuickStick HT User Manual

Installation
Transport System Installation
Connector Kit Specifications
Table 5-5: Universal Feedback Connector Kit Wiring Requirements
Attribute
Cable diameter
Screw terminal wire size
Recommended wire strip length
Recommended torque
Mounting screws
Terminal screws
Clamp and cover screws
Kit contents
204
6.5...11.9 mm (0.26...0.47 in.)
0.08...1.5 mm2 (28...16 AWG)
5 mm (0.2 in.) single conductor
0.39 N•m (3.5 lb•in)
0.22...0.25 N•m (1.9...2.2 lb•in)
0.34 N•m (3.0 lb•in)
• Connector kit
• Parts bag containing:
- 1 cover screw, and 1 spare, #4-20, (0.375 in.)
- 2 clamp screws, and 1 spare, #4-40, (0.25 in.)
- 1 shield clamp
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Value
MagneMotion
