MICS File Protocol

The MICS file protocol defines the XML elements and structure that is used to identify the
motors, their MAC address, IP address, and location on a path. These elements are only used
in the MICS file.

MICS File XML Reference

The XML tags that are shown in
Element
XML Declaration
MICS_motor_data
Motor
Mac_addr
IP_addr
Track_location
Orientation
QuickStick HT User Manual
Table 3-4
Table 3-4: MICS File XML Elements
Start of the document.
Root tag for MICS motor configuration data.
Container tag that defines the MICS data for a motor.
The MAC address of the drive for the motor.
The static IPv4 address of the drive for the motor.
The motor position in the specified path.
The orientation of the motor in the specified path.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
are used to define and configure the MICS file.
Description
Design Guidelines
Transport System Design
Page
92
93
94
95
96
97
98
91
