Symbol Identification

Symbol Identification
Symbols are used in this manual and on the MagneMotion products to identify hazards, man-
datory actions, and prohibited actions. The symbols that are used in this manual and their
descriptions are provided in the following tables.
Symbol
kg
46
Table 2-2: Hazard Alert Symbol Identification
General Hazard – Indicates that failure to follow recommended procedures
can result in unsafe conditions, which could cause injury or equipment dam-
age.
Lifting Hazard – Indicates that the specified object is heavy or awkward to
handle. Personnel must use lifting aids and proper techniques for lifting to
avoid muscle strain or back injury.
Automatic Motion Hazard – Indicates the possibility of machinery auto-
matically starting or moving, which could cause personal injury.
Shock Hazard – Indicates that a severe shock hazard is present that could
cause personal injury.
Magnetic Field Hazard – Indicates that a strong magnetic field is present
that could cause personal injury.
Crush Hazard – Indicates that there are exposed parts that move, which
could cause personal injury from the squeezing or compression of fingers,
hands, or other body parts between those parts.
