Specifications and Site Requirements
Electrical Specifications
700-1550-xx
Motor Controller
Stator Block, Phase A
Stator Block, Phase B
Stator Block, Phase C
—
—
—
GND
NOTICE
136
Figure 4-11: 1/2 m QSMC to Stator Drive Cable
Table 4-6: 1/2 m QSMC to Stator Drive Cable Pinouts
Motor Controller
1
Wire MINI-CON-X, 4-Pin,
Gauge
16 AWG
16 AWG
16 AWG
—
—
—
16 AWG
Modifications to the MMI motor to motor controller cables,
or using custom cables, violates the UL conditions of accept-
ability.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
A
1 4
2 3
3-Pt Reverse Bayonet,
Male
3
2
1
—
—
—
4
Motor
Motor
16S-1, Female
A
B
C
D
E
F
G
