Specifications and Site Requirements
Electrical Specifications
Label
Stator Sense B
Digital In
Ground
Stator Inverter Output A 8.9 kW@ 324–528V rms,
Stator Inverter Output B 8.9 kW@ 324–528V rms,
Label
Display Navigation
Label
Module Status
Network Status
LCD Display
156
Table 4-33: QSHT 5700 Inverter Connections (Continued)
Description
Magnet array position sense
4 digital inputs
Ground
three-phase, 13.0 A rms continu-
ous, 20 A max
three-phase, 13.0 A rms continu-
ous, 20 A max
Table 4-34: QSHT 5700 Inverter Controls
Navigation controls for LCD display using soft menus
Table 4-35: QSHT 5700 Inverter Indicators
Displays control power status
Displays network connection status
Displays general module status
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
10 Pin, Terminal Block
DE-15, Female
Phillips head screw
4 Pin Terminal Block
4 Pin Terminal Block
Description
Description
Connector Type
Control Type
Push Button
Indicator Type
Red/Green LED
Red/Green LED
LCD Display
MagneMotion
