• When attaching mounting brackets to the motors and securing the brackets to the track
as shown in
motor connections. This mounting method provides easy adjustment of the motor
position once the motor is installed.
QSHT Motor
Track
When using either of the mounting methods shown.
1. Loosely mount the motors to the motor mounting surface. The motor mounts should
allow the motors a small amount of movement relative to each other.
NOTE: The upstream end of the motor has a hole for alignment with a locating pin
2. Make sure that there is consistent spacing between the motors.
3. Make sure that the top surfaces of all motors are coplanar to each other.
4. Treating each motor to motor interface as a separate operation, tighten the motor
mounts. See
QuickStick HT User Manual
Figure 3-39, make sure that the brackets are located to allow access to all
Figure 3-39: Motor Mounting Using Brackets
and the downstream end of the motor has a slot for alignment with a second
locating pin (see Figure 4-1 on page 124
Mounting the Motors on page 181
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Design Guidelines
Transport System Design
Mounting Bracket Hardware
Motor Mounting Bracket
M6 Motor Mounting Hardware
through Figure 4-3 on page
for details of the mounting procedure.
126).
