Each soft menu item is executed by pressing the navigation button directly below that item.
The soft menu provides a changing selection that corresponds to the current screen. The func-
tions available through the soft menu display are shown in
Menu/Submenu
HOME
SETTINGS
DISPLAY
QuickStick HT User Manual
Table 4-49: Soft Menu Functions
Press to go back. Pressing enough times returns to the
Home screen.
Pressing the button for either arrow moves the selection
to the next (or previous) item. When changing values,
pressing the up arrow increments the highlighted value.
Values roll over after reaching the end of the list.
Press to select values to change, moving from right to
left. Values roll over when reaching the end of the list.
Press to select the highlighted menu item.
Press to return to the Home screen.
Press to display the fault help (possible solutions in trou-
?
bleshooting tables).
Table 4-50: LCD Pages
Drive status displayed in footer:
INITIALIZATION – System is starting.
MOVEMENT SUSPENDED – Movement is suspended due to
active faults.
MAJOR FAULT – System is in fault state.
IP Address or Mac Address:
If the IP address is not provisioned, the Mac Address is displayed.
Cyclical Data (one of the following displays depending on the selec-
tion made on the CYCLIC DATA SELECT page):
DC BUS – The DC bus voltage of the currently selected inverter.
INV TEMP – Temperature of the currently selected inverter.
MOTOR TEMP – Temperature of the motor, supplied by the cur-
rently selected inverter.
OUT CURR – Output current as commanded by the currently
selected inverter.
DISPLAY – The display page selection.
BACKLIGHT TIMEOUT – Selects BACKLIGHT TIMEOUT page.
CYCLIC DATA SELECT – Selects CYCLIC DATA SELECT page.
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Specifications and Site Requirements
Electrical Specifications
Figure 4-49.
