Oracle Fabric Interconnect Series User Manual page 90

Connect Power for the Fabric Interconnect F1-4
FIGURE 57
On the opposite side of Oracle Fabric Interconnect, simultaneously switch all
2.
power supplies to the "On" position.
Connect Power for the Fabric Interconnect F1-4
The Fabric Interconnect F1-4's power supplies and power plugs are located on the front of the
chassis. See below.
Caution -
power source and the Fabric Interconnect (such as surge suppressors, plug bars, and so on)
meet these requirements: – 100 - 127 / 200 - 240 V AC – 4 - 8.5 A – 50 - 60 Hz – 750 W
(maximum)
90 Oracle Fabric Interconnect Hardware User's Guide • July 2016
Fabric Interconnect F1-15 Power Supplies for Connecting to AC Facility Power
Verify that your AC power source, as well as any equipment installed between the
