slots in the rack-depth rails and tighten them into the screw holes in the right
angle brackets (2).
Note -
You might find it helpful to tighten the screws to finger tightness or just less. By doing
so, you allow the Fabric Interconnect to slide forward and backward in the rack-depth rail's
slots, and as a result, you can make minor adjustments to the Fabric Interconnect's depth in the
rack (if needed).
4.
Install the Cable Management Assembly (CMA) as documented in
Cable Management Assembly" on page
The same CMA is supported for both the Oracle Fabric Interconnect F1-15 and Oracle Fabric
Interconnect F1-4, so use the same procedure. Where illustrations show the Oracle Fabric
Interconnect F1-15, you will substitute the Oracle Fabric Interconnect F1-4.
5.
Install the I/O modules as documented in
Module" on page
Cable the Fabric Interconnect F1-4 as documented in
6.
Interconnect to Other Equipment" on page
7.
When the Fabric Interconnect F1-4 is installed on the rack and cabled to the
other equipment, you will plug in the power cords and anchor the power cables
in place as documented in
Attach the Right Angle Bracket in a 27-Inch Sun/
Oracle Rack
1.
Align the 27-inch angle bracket for the Oracle Fabric Interconnect F1-4 so that it
is outside of the side panels.
From inside the side panels, insert the M3.5 flat-head screws through the slots in
2.
the side panel and into the angle bracket's screw holes.
See
Figure 28, "Aligning the Angle Brackets and Inserting the Screws," on page
angle bracket requires 3 screws.
Attach the Right Angle Bracket in a 27-Inch Sun/Oracle Rack
69.
"AC Power" on page
37.
"Installing an I/O
"Connecting the Fabric
77.
89.
Installing the Fabric Interconnect
"Installing the
56. Each
55
