Replacing a Fabric Board

The PSU is correctly seated when the locking tab clicks into place.
3. Reconnect the power cord. Be aware that the power cord might have jostled in
the tie wrap.
Note -
requirements documented in
Replacing a Fabric Board
The Fabric Interconnect contains 24 InfiniBand ports that connect to client servers. Each port
is a double data rate (DDR) link to the server and operates at 20 Gbps, but will auto negotiate
down to Single Data Rate (SDR) based on the devices that the Fabric Interconnect is connected
to. Ports are numbered left to right starting at the bottom left-hand corner.
This section documents how to replace the InfiniBand Fabric Board. For this procedure, you
will need to power off the Fabric Interconnect.
To perform this procedure, you will need the following tools:
#2 Phillips (cross-head) screwdriver
■
an ESD wrist strap
■
Caution -
overtighten screws or they can break.
Caution -
out of its shipping package or not in the Fabric Interconnect chassis, make sure you place it in
an ESD safe bag or on a grounded work surface such as a rubberized work mat.
See the appropriate section:
"Replace the Fabric Interconnect F1-15 DDR Fabric Board" on page 113
■
"Replace the Fabric Interconnect F1-4 DDR Fabric Board" on page 114
■
"Replace the Fabric Interconnect F1-15 QDR Fabric Board" on page 118
■
"Replace the Fabric Interconnect F1-4 QDR Fabric Board" on page 123
■
"Upgrading a DDR Fabric Board to a QDR Fabric Board" on page 128
■
"Upgrade a Fabric Interconnect F1-15 to a QDR Fabric Board" on page 129
■
"Upgrade a Fabric Interconnect F1-4 to a QDR Fabric Board" on page 134
■
112 Oracle Fabric Interconnect Hardware User's Guide • July 2016
When reconnecting power cords after servicing the power supplies, make sure read the
"Power Cord Management" on page
When tightening screws, make sure to tighten them to lightly snug. Do not
When replacing the Fabric Board: - wear an ESD wrist strap - When the hardware is
46.
