Oracle Fabric Interconnect Series User Manual page 18

Unpack the Fabric Interconnect F1-15
Rail Kit box
■
Accessory Kit
■
System information packet
■
2. Open the containers and verify their contents against the illustration in
"Unpacking Shipping Containers and Examining Contents," on page
Unpacking Shipping Containers and Examining Contents
FIGURE 3
Note -
box. In addition, a module retention bracket (also not shown) is attached to the F1-15 chassis
to keep modules and blanks secure while shipping. The CMA can be installed as an option (see
"Installing the Cable Management Assembly" on page
you must remove the module retention bracket.
3. Unpack the Fabric Interconnect chassis and place it on a flat, stable surface
capable of supporting up to 170 pounds (77.11kg).
18 Oracle Fabric Interconnect Hardware User's Guide • July 2016
Although not pictured, a cable management assembly (CMA) is included in a separate
37. However, to install I/O Modules,
Figure 3,
18.
