Attach The Right Angle Bracket - Oracle Fabric Interconnect Series User Manual

"Attach the Right Angle Bracket in a 27" Sun/Oracle Rack" on page 35
■

Attach the Right Angle Bracket

Slide the Fabric Interconnect into the rack until the front mounting brackets
1.
make contact with the front rack posts. See
Depth Measures to the Angle Brackets," on page
FIGURE 26 Attaching the Rack Depth Measures to the Angle Brackets
Keeping the Fabric Interconnect level, insert the appropriate rack mounting
2.
screws (10-32, 12-24, or M6) into the mounting brackets on the front of the Fabric
Interconnect (the fan unit end). See
Brackets to the Equipment Rack," on page
Use two (2) pan-head screws per bracket. Use the appropriate screw for your rack type:
Figure 26, "Attaching the Rack
53.
Figure 27, "Securing the Front Mounting
54.
Installing the Fabric Interconnect
Attach the Right Angle Bracket
53
