Replace the Fabric Interconnect F1-4 QDR Fabric Board
FIGURE 79
4. When the screws are loose, grasp the Fabric Board's handles and
simultaneously pivot them outward (2) as shown in
Fabric Interconnect F1-4's Fabric Board," on page
levers that disconnect the Fabric Board from the Fabric Interconnect F1-4
midplane. As a result, you might encounter some resistance when you first
apply pressure to pivot the handles outward.
Caution -
upward or downward pressure on the Fabric Board's handles when you are removing the Fabric
Board. You need to pivot the Fabric Board handles outward just until you feel the Fabric Board
disconnect from the midplane. Do not force the Fabric Board handles wider than is required to
disconnect the Fabric Board.
After the Fabric Board has disconnected from the Fabric Interconnect F1-4
5.
midplane, gently slide the Fabric Board out of the chassis, making sure to
support the Fabric Board from underneath (the sheet metal side). See
"Removing the Fabric Interconnect F1-4 Fabric Board," on page
124 Oracle Fabric Interconnect Hardware User's Guide • July 2016
Unlocking the Fabric Interconnect F1-4's Fabric Board
Make sure to pivot the Fabric Board handles in a horizontal plane. Do not apply
Figure 79, "Unlocking the
124. The handles act as
Figure 80,
125.
