Install the CMA

Four (4) 10-32 x .375 inch Phillips pan-head screws
■
Four (4) 12-24 x .5 inch Phillips pan-head screws
■
Four (4) #12 locking washers (for use with 12-24 screws)
■
Four (4) M4 x 10 mm Phillips flat-head screws
■
Note -
The type of screw that you will use depends on the type of rack you have. For example,
if you have a Sun/Oracle rack, you will use the M6 cage nuts and the M6 screws to attach
the CMA to the rack. Be aware that you will not use every type of screw, just the type
appropriate for your equipment rack.
Install the CMA
To install the CMA, follow this procedure:
1. Using tape or a marker, make two horizontal marks, one on each of two rack
posts. These marks must be level because they will indicate where the CMA will
be attached to the rack.
2. Slide the attachment bracket over the extender, so that the tab on the bracket is
opposite the flange on the extender as shown in
sliding over the Long Rail," on page
The open end of the tab is toward the flange. The flat end of the tab is toward the rear of the
extender.
38 Oracle Fabric Interconnect Hardware User's Guide • July 2016
Oracle provides four of each type of screw for mounting the CMA to the rack.
Figure 16, "Attachment Bracket
39.
