4.
When the module is completely inserted, it should lie flush with the face of the
Fabric Interconnect F1-4.
5.
Using a slotted screwdriver, lock the I/O Module into the chassis by turning
the lock 90 degrees clockwise (2) as shown in
Interconnect F1-4 I/O Module," on page
Removing and Installing the Management Module
This section documents how to remove and install the Management module. You must power
down the Fabric Interconnect to perform this procedure. To perform this procedure, you will
need a #2 Phillips (cross-head) screwdriver.
Caution -
overtighten screws or they can break.
Caution -
hardware is out of its shipping package or the Fabric Interconnect chassis, make sure you place
it in an ESD safe bag or on a grounded work surface such as a rubberized work mat.
See the appropriate section:
"Remove a Fabric Interconnect F1-15 Management Module" on page 147
■
"Removing and Installing the Fabric Interconnect F1-4 Management
■
Module" on page 149
Remove a Fabric Interconnect F1-15 Management
Module
On a Fabric Interconnect F1-15, the Management module can only be installed in slot 16, which
is labelled M.
To remove the Fabric Interconnect F1-15 Management module, follow this procedure:
1.
Power down the Fabric Interconnect.
Disconnect any cables attached to the Management module.
2.
3.
Using the screwdriver, release the spring-loaded securing screw (1), located
at the bottom edge of the module. See
Interconnect F1-15 Management Module," on page
When tightening screws, make sure to tighten them to lightly snug. Do not
When replacing the Management Modules: - wear an ESD wrist strap - When the
Removing and Installing the Management Module
Figure 94, "Installing a Fabric
146.
Figure 95, "Removing the Fabric
148.
Performing Service Tasks
147
