Return the Oracle Fabric Interconnect to Service

Re-install the Oracle Fabric Interconnect into the rack:
Note -
types, but be aware that there are extra steps required to install the chassis in a 27-inch Sun/
Oracle equipment rack.
For an Oracle Fabric Interconnect F1-15 in a four-post rack or a 27-inch Sun/Oracle rack,
■
see
For an Oracle Fabric Interconnect F1-4 in a four -post rack or a 27-inch Sun/Oracle rack,
■
see,

Return the Oracle Fabric Interconnect to Service

1. Reconnect the InfiniBand, Gigabit Ethernet, and FibreChannel cables.
See "Connecting the Fabric Interconnect to Other Equipment" on page
Reconnect the Oracle Fabric Interconnect to facility power.
2.
See "AC Power" on page
3. Complete the Oracle First Boot wizard.
See "Initial Configuration" on page

Cables and Connectors for 4-Port 10 GE Module

Connection to the 4-Port 10 GE Module is supported through either optical or copper cables.
Cables and connectors come in either of the following options:
Standalone SFP+ port transceivers that plug into an empty port cage on the module. The
■
optical Gigabit Ethernet cable then inserts into the transceiver. Use this arrangement if you
will be connecting the 4-Port 10 GE module to an optical environment.
An SFP+ cable (passive or active copper cabling):
■
■
■
166 Oracle Fabric Interconnect Hardware User's Guide • July 2016
The majority of the following chassis-installation procedures is common to both rack
"Installing the Fabric Interconnect F1-15 in a 4-Post Rack" on page
"Install the Fabric Interconnect F1-4" on page
89.
Active copper cabling is a Gigabit Ethernet copper cable with the SFP+ port transceiver
embedded into both ends of the cable. Because the SFP+ transceiver is part of the cable,
the cable then plugs into the empty port cage on the 4-Port 10 GE Module.
Passive copper cabling does not have the transceiver embedded. Use this arrangement if
you will be connecting the 4-Port 10 GE module to a copper environment.
Notice that the maximum cable length supported for passive copper cables is 5
Note -
meters, as indicated in Table 3, " Supported SFP+ Copper Cables," on page
49.
95.
20.
77.
167.
