Oracle Talari T5200 Hardware Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Oracle Talari T5200
Hardware Guide
Original Publication Date:
Nov 1, 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Talari T5200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oracle Talari T5200

Summary of Contents for Oracle Talari T5200

  • Page 1 Oracle Talari T5200 Hardware Guide Original Publication Date: Nov 1, 2019...
  • Page 2 This software or hardware and documentation may provide access to or information on content, products, and services from third parties. Oracle Corporation and its affiliates are not responsible for and expressly disclaim all warranties of any kind with respect to third-party content, products, and services. Oracle...

  • Page 3: Table Of Contents

    Oracle Talari T5200 | Hardware Guide Table of Contents Table of Contents ............................3 About This Document ..............................4 Audience ................................4 Reference Documents ............................4 Hardware and Software Requirements ......................... 5 About the Oracle Talari Appliance ......................... 6 Oracle SD-WAN Overview ..........................6 Front Panel Configuration ..........................

  • Page 4: About This Document

    For non-technical issues such as registration or assistance with My Oracle Support, select You are connected to a live agent who can assist you with My Oracle Support registration and opening a support ticket. My Oracle Support is available 24 hours a day, 7 days a week, 365 days a year.

  • Page 5: Table Of Contents

    Loss of the system ability to provide any required critical or major trouble notification Any other problem severely affecting service, capacity/traffic, billing, and maintenance capabilities may be defined as critical by prior discussion and agreement with Oracle. Locate Product Documentation on the Oracle Help Center Site Oracle Communications customer documentation is available on the web at the Oracle Help Center (OHC) site, http://docs.oracle.com.

  • Page 7: Hardware And Software Requirements

    Oracle Talari T5200 | Hardware Guide Hardware and Software Requirements The T5200 has the following hardware and software requirements: Hardware: The appliances must be mounted in a standard, 19-inch (480mm), four-post rack. Software: The Talari Adaptive Private Networking (APN) Software, which comes pre-...

  • Page 8: About The Oracle Talari Appliance

    Links and connects up to 256 sites. Oracle SD-WAN Overview Talari redefined WAN reliability and application performance with its family of Oracle Talari Appliances. By adding Oracle Talari Appliances to existing networks, customers can aggregate and transform affordable broadband connections to deliver enterprise class performance and reliability at consumer prices.

  • Page 9: Rear Panel Configuration

    Oracle Talari T5200 | Hardware Guide Rear Panel Configuration The T5200 rear panel contains the following components:  One VGA monitor port  Four USB 2.0 ports  One DB9 console port  One management port  One auxiliary port (limited to 100 Mbps full duplex) ...

  • Page 10: Ethernet Ports

    Oracle Talari T5200 | Hardware Guide Ethernet Ports Port Ethernet Type Description Copper Gigabit Management port (dedicated – out of band) Multi-mode Fiber 10 Gigabit (SFP+) User defined; forms a Bypass pair with Port 2 Multi-mode Fiber 10 Gigabit (SFP+) User defined;...

  • Page 11: Lan/Wan Port Connectivity

    Oracle Talari T5200 | Hardware Guide Figure 5: 1 Gigabit Bypass Interfaces LAN/WAN Port Connectivity Connect a configured Ethernet LAN port to the LAN side of your network. Connect the corresponding configured WAN port to the WAN side of your network. As illustrated in...

  • Page 12: Untrusted Interfaces

    Oracle Talari T5200 | Hardware Guide changed via the web console. Follow the instructions in the Talari Appliance Quick Start Guide to configure the T5200. Untrusted Interfaces Ethernet ports may be configured as untrusted interfaces. Untrusted interfaces connect to untrusted zones that the administrator does not want to place within the normal switched or routed enterprise network because of security or convenience.

  • Page 13: Installing The Talari Appliance

    Oracle Talari T5200 | Hardware Guide Installing the Talari Appliance Rack Installation Prior to installing the system in a rack, adhere to the following rack installation guidelines:  Ensure that there is adequate airflow through the rack, because restricted airflow can lead to equipment damage.
  • Page 14 Oracle Talari T5200 | Hardware Guide Figure 7: Rail Assembly...
  • Page 15 Oracle Talari T5200 | Hardware Guide 2. Extend the rail assembly by pulling it outward. Figure 8: Extend Rail Assembly 3. Press the quick-release tab as illustrated in Figure 8 1. Separate the inner rail extension from the outer rail assembly.

  • Page 16: Attaching Inner Rails

    Oracle Talari T5200 | Hardware Guide Attaching Inner Rails 1. Attach one inner rail to each side of the appliance by aligning the holes in the bracket with the corresponding hooks on the appliance. 2. Slide the rails into place on the appliance.

  • Page 17: Attaching Outer Rails To The Rack

    Oracle Talari T5200 | Hardware Guide Attaching Outer Rails to the Rack 4. Secure the back end of the outer rail to the rack by placing the hooks of the rails into the rack holes and securing the outer rail with the screws included in the rack mounting kit.

  • Page 18: Adding Your T5200 To The Rack

    Oracle Talari T5200 | Hardware Guide Adding Your T5200 to the Rack 1. Extend the outer rails as illustrated in Figure 13 2. Align the inner rails attached to the chassis with the outer rails attached to the rack. 3. Slide the inner rails into the outer rails, keep the pressure even on both sides, and push the chassis into the rack.

  • Page 19: Connecting Power To The Appliance

    Important Note about Cabling and Bypass Mode When your Oracle Talari Appliance is operating in bypass mode (e.g., when it is powered off), the appliance acts like a crossover cable. This may cause a loss of the link between the appliance and older network devices that do not support Auto MDI-X when straight-through cables are used to connect the LAN and WAN ports of the appliance.

  • Page 20: Powering Up The Appliance

    Oracle Talari T5200 | Hardware Guide Powering Up the Appliance Checklist for Power Up Power up the T5200 by performing the following steps: 5. Determine the IP address for the Ethernet management interface. 6. Confirm that the chassis is securely mounted.

  • Page 21: Troubleshooting

    Oracle Talari T5200 | Hardware Guide Troubleshooting The following section outlines some troubleshooting steps and guidelines for the T5200. Basic Troubleshooting The key to problem solving is to isolate the problem to a specific subsystem by comparing what the appliance is doing to what it should be doing. The T5200 has LEDs and NIC indicators on the rear panel for the indication of power, disk activity, Ethernet activity, etc.
  • Page 22 Oracle Talari T5200 | Hardware Guide Important Note about Cabling and Bypass Mode Please also see for additional information. Problem Resolution Bypass mode blocking traffic Verify that the T5200 has connectivity to the L2/L3 devices on its LAN/WAN ports. Verify that the correct cables are used and that the networking devices have auto-negotiate set for their ports.
