- Page 1 Oracle Talari T3010/T5000 Hardware Guide Original Publication Date: Nov 1, 2019...
- Page 2 If you use this software or hardware in dangerous applications, then you shall be responsible to take all appropriate fail-safe, backup, redundancy, and other measures to ensure its safe use. Oracle Corporation and its affiliates disclaim any liability for any damages caused by use of this software or hardware in dangerous applications.
-
Page 3: Table Of Contents
| Oracle Talari T3010/T5000 | Hardware Guide Table of Contents Table of Contents ............................... 3 About This Document .................................. 4 Audience ................................... 4 Reference Documents ............................... 4 Hardware and Software Requirements ..........................5 About the Oracle Talari Appliance ............................6 Oracle SD-WAN Overview .............................. -
Page 4: About This Document
A representative at Customer Access Support (CAS) can assist you with My Oracle Support registration. Call the CAS main number at 1-800-223-1711 (toll-free in the US), or call the Oracle Support hotline for your local country from the list at http://www.oracle.com/us/support/contact/index.html. When calling, make the selections in the sequence shown below on the Support telephone menu: 1. - Page 5 For non-technical issues such as registration or assistance with My Oracle Support, select You are connected to a live agent who can assist you with My Oracle Support registration and opening a support ticket. My Oracle Support is available 24 hours a day, 7 days a week, 365 days a year.
-
Page 6: Table Of Contents
Oracle. Locate Product Documentation on the Oracle Help Center Site Oracle Communications customer documentation is available on the web at the Oracle Help Center (OHC) site, http://docs.oracle.com. You do not have to register to access these documents. Viewing these files requires Adobe Acrobat Reader, which can be downloaded at http://www.adobe.com. -
Page 7: Audience
4. Select the Release Number. A list of the entire documentation set for the selected product and release appears. 5. To download a file to your location, right-click the PDF link, select Save target as (or similar command based on your browser), and save to a local folder. Reference Documents The following documents are available: ... -
Page 8: Hardware And Software Requirements
| Oracle Talari T3010/T5000 | Hardware Guide Hardware and Software Requirements The T3010 and T5000 have the following hardware and software requirements: Hardware: The appliances must be mounted in a standard, 19-inch (480mm), four-post rack. Software: The Talari Adaptive Private Networking (APN) Software, which comes pre-installed on all... -
Page 9: About The Oracle Talari Appliance
3Gbps across eight WAN Links and connecting up to 256 sites. Oracle SD-WAN Overview Talari redefined WAN reliability and application performance with its family of Oracle Talari Appliances. By adding Oracle Talari Appliances to existing networks, customers can aggregate and transform affordable broadband connections to deliver enterprise class performance and reliability at consumer prices. -
Page 10: Rear Panel Configuration
| Oracle Talari T3010/T5000 | Hardware Guide Rear Panel Configuration The T3010 and T5000 rear panels contain the following user interface ports: A VGA monitor port Four USB 2.0 ports One DB9 console port One management port ... -
Page 11: Nic Indicator Codes
| Oracle Talari T3010/T5000 | Hardware Guide NIC Indicator Codes Ethernet ports on the rear panel have indicator lights for information on network activity and link status. Figure 3: Management Interfaces Figure 4: Bypass Interfaces... -
Page 12: Lan/Wan Port Connectivity
| Oracle Talari T3010/T5000 | Hardware Guide LAN/WAN Port Connectivity Connect a configured Ethernet LAN port to the LAN side of your network. Connect the corresponding configured WAN port to the WAN side of your network. As illustrated in port 1 corresponds to Figure port 2, while port 3 corresponds to port 4. -
Page 13: Hardware Specifications
| Oracle Talari T3010/T5000 | Hardware Guide Hardware Specifications The T3010 and T5000 have the following hardware specifications: Specification Power 100-240 volts 50-60 Hz, 9-3.5 Amp Redundant 740W ATX AC power supply UL approved, FCC compliant EIA RS-310 standards 2U Physical Dimensions 437mm (W) x 648mm (D) x 89mm (H) (17.2”... -
Page 14: Installing The Talari Appliance
| Oracle Talari T3010/T5000 | Hardware Guide Installing the Talari Appliance Rack Installation Prior to installing the system in a rack, adhere to the following rack installation guidelines: Ensure that there is adequate airflow through the rack, because restricted airflow can lead to equipment damage. - Page 15 | Oracle Talari T3010/T5000 | Hardware Guide 2. Extend the rail assembly by pulling it outward. Figure 7: Extend Rail Assembly 3. Press the quick-release tab as illustrated in Figure 7 1. Separate the inner rail extension from the outer rail assembly.
-
Page 16: Attaching Inner Rails
| Oracle Talari T3010/T5000 | Hardware Guide Attaching Inner Rails 1. Attach one inner rail to each side of the appliance by aligning the holes in the bracket with the corresponding hooks on the appliance. 2. Slide the rails into place on the appliance. -
Page 17: Attaching Outer Rails To The Rack
| Oracle Talari T3010/T5000 | Hardware Guide Attaching Outer Rails to the Rack 4. Secure the back end of the outer rail to the rack by placing the hooks of the rails into the rack holes and securing the outer rail with the screws included in the rack mounting kit. -
Page 18: Adding Your T3010/T5000 To The Rack
| Oracle Talari T3010/T5000 | Hardware Guide Adding Your T3010/T5000 to the Rack 1. Extend the outer rails as illustrated in Figure 12 2. Align the inner rails attached to the chassis with the outer rails attached to the rack. -
Page 19: Important Note About Cabling And Bypass Mode
Important Note about Cabling and Bypass Mode When your Oracle Talari Appliance is operating in bypass mode (e.g., when it is powered off), the appliance acts like a crossover cable. This may cause a loss of the link between the appliance and older network devices that do not support Auto MDI-X when straight-through cables are used to connect the LAN and WAN ports of the APNA. -
Page 20: Troubleshooting
| Oracle Talari T3010/T5000 | Hardware Guide The T3010 and T5000 ship with a default management IP address of 192.168.0.2/30. In order to access your appliance remotely, you must first connect to it directly via the Management Auxiliary interface (AUX) and configure a management IP address for the appliance. -
Page 21: Troubleshooting Bypass Mode (Fail-To-Wire)
| Oracle Talari T3010/T5000 | Hardware Guide Troubleshooting Bypass Mode (Fail-to-Wire) The T3010 and T5000 are equipped with a capability known as “bypass mode” or “fail-to-wire.” This capability is designed to prevent a single point of failure. If there is a serious problem with the appliance, the bypass pair enters bypass mode and forwards traffic through as though the appliance were a wire.
